Description
Thermal Imaging Detector and Lens
Array Format: 640×512, 12μm
NETD: ≤40mK @25°C
Focal Length: 270mm
CMOS and Lens
Array Format: 1024×768, 1.3μm
FOV: 16°×12°
Laser Ranging
Maximum Range: 25km
Ranging Accuracy: ≤ 2m
Others
Focusing: Manual
Frame Rate: 25Hz
Display: 0.39″ OLED, resolution 1024×768
Digital Zoom: 1–4 times, Zoom ring focus
Image Adjustment: Brightness, contrast, background correction, auto/manual shutter calibration, polarity, image enhancement
Image Modes: White Hot, Black Hot, Fusion Color
Target Memory: Detection and distance of five multiple targets can be recorded in real-time
Detection: Human 1.7m × 0.5m: 5km
Recognition: Vehicle 2.3m × 2.3m: 25km
Image Storage Format
Image Format: BMP or JPEG
Storage Capacity: 32G
Topology: RNG (analog, USB(Digital), RS232(Control))
Rangefinder: Built-in
Compass: Electronic, Accuracy ≤3°
Power Supply: Three 18650 rechargeable lithium batteries
Battery Working Time: ≥6h
Operating Temperature: -40°C ~ +55°C
IP Rating: IP66
Weight: 895g (including batteries and eye cup)
Size: 185mm×110mm×70mm
